NX8663JB-BC

R08DS0063EJ0100 Rev.1.00

Page 2 of 5

Jul 05, 2012

PACKAGE DIMENSIONS (UNIT: mm)

Optical Fiber

SMF,

Length: 1 m MIN.

#14

–

BOTTOM VIEW

Thermistor

Case

Cooler Anode

Laser Anode,

Case Ground

Laser Cathode

Laser Anode,

Case Ground

Thermistor

Cooler Cathode

Pin No.

PIN CONNECTIONS

Function

1.0

20.8

21.3

4.0

3.2

5.1

2.54

0.45

3.0

OPTICAL FIBER CHARACTERISTICS

Parameter

Specification

Unit

Mode Field Diameter

9.3

± 0.5

μm

Cladding Diameter

125

±2

μm

Maximum Cladding Noncircularity

Maximum Core/Cladding Concentricity

1.6

Outer Diameter

0.9

±0.1

Cut-off Wavelength

1 100 to 1 280

Minimum Fiber Bending Radius

Fiber Length

1 000 MIN.

Flammability

UL1581 VW-1

FC-UPC Connector

Fiber Length: 1 000 mm MIN.
