SCF2920 Series

SOCAY Electronics Co., Ltd.

www.socay.com

Part Number

Packaging Option

Quantity

SCF030-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF050-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF075-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF075-60-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF100-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF125-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF150-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF185-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF200-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF200-24-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF250-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF260-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF300-2920-R

Tape & Reel -16mm/7

″tape

2000

SCF300-15-2920R

Tape & Reel -16mm/7

″tape

2000

u

Operation beyond the specified maximum ratings or improper use may result in damage and possible electrical arcing and/or

flame.

u

PPTC device are intended for occasional over-current protection. Application for repeated over-current condition and/or

prolonged trip are not anticipated.

u

Avoid contact of PPTC device with chemical solvent. Prolonged contact will damage the device performance.

Packaging

Warning

Tape and Reel Specifications

Direction of Feed

0.646

(16.4)

0.512(13.0)

Arbor Hole Diameter

7.0

(177.8)

Packag

Dimensions are in inches

(and millimeters)

0.157

(4.0)

0.059

(1.5)

Diameter

Cover tape

0.630

(16.0)

0.315

(8.0)

0.524

(13.3)
