Surface Mount Resettable PTCs

Revision September 12, 2013

3 / 4

@ SOCAY Electronics Co., Ltd. 2013

Specifications are subject to change without notice.

Please refer to www.socay.com for current information.

SCF1210 Series

SOCAY Electronics Co., Ltd.

www.socay.com

Example

Device

Nominal

1210 Series

2.00

1.00

2.80

The dimension in the table below provide the recommended

pad layout for each SCF1210 device

Part Number

Min.

Max.

Min.

Max.

Min.

Max.

Min.

Max.

Min.

Max.

SCF005-1210-R

3.00

3.43

2.35

2.80

0.60

1.15

0.25

0.75

0.10

0.45

SCF010-1210-R

3.00

3.43

2.35

2.80

0.60

1.15

0.25

0.75

0.10

0.45

SCF020-1210-R

3.00

3.43

2.35

2.80

0.40

0.85

0.25

0.75

0.10

0.45

SCF035-1210-R

3.00

3.43

2.35

2.80

0.40

0.80

0.25

0.75

0.10

0.45

SCF050-1210-R

3.00

3.43

2.35

2.80

0.30

0.75

0.25

0.75

0.10

0.45

SCF075-1210-R

3.00

3.43

2.35

2.80

0.30

0.70

0.25

0.75

0.10

0.45

SCF075-24-1210R

3.00

3.43

2.35

2.80

0.90

1.30

0.25

0.75

0.10

0.45

SCF110-1210R

3.00

3.43

2.35

2.80

0.60

1.00

0.25

0.75

0.10

0.45

SCF150-1210R

3.00

3.43

2.35

2.80

0.50

0.90

0.25

0.75

0.10

0.45

SCF175-1210R

3.00

3.43

2.35

2.80

0.80

1.40

0.25

0.75

0.10

0.45

SCF200-1210R

3.00

3.43

2.35

2.80

0.80

1.40

0.25

0.75

0.10

0.45

Dimensions

Unit: mm

Part Numbering

Part Marking

Pad Layouts

Unit: mm

SCF XXX

– XX – 1210R

Device Size Code

Voltage Rating

Current Rating

Socay Product Code

F75

F XX

Part Identification

Logo

F XX

Part Identification

Logo
