108

sReceptacle (SMT)

Note1: Tape and reel packaging(500 pieces/reel). Order by number of reels.

Note2: The 40 contacts connector is marchandized only in combination with the SMT product.

Note3: Embossed packaging products have the reel wrapped in polyethylene and include a desiccant.

Unit: mm

Part Number

CL No.

DF11CZ- 4DS-2V(**)

DF11CZ- 6DS-2V(**)

DF11CZ- 8DS-2V(**)

DF11CZ-10DS-2V(**)

DF11CZ-18DS-2V(**)

DF11CZ-20DS-2V(**)

DF11CZ-22DS-2V(**)

DF11CZ-26DS-2V(**)

DF11CZ-30DS-2V(**)

DF11CZ-40DS-2V(**)

CL543-2063-0-**

CL543-2064-3-**

CL543-2065-6-**

CL543-2066-9-**

CL543-2070-6-**

CL543-2071-9-**

CL543-2072-1-**

CL543-2074-7-**

CL543-2076-2-**

CL543-0584-2-**

4

6

8

10

18

20

22

26

30

40

2.0

4.0

6.0

8.0

16.0

18.0

20.0

24.0

28.0

38.0

8.5

10.5

12.5

14.5

22.5

24.5

26.5

30.5

34.5

44.5

Number of Contacts

A

B

C

8.7

10.7

12.7

14.7

22.7

24.7

26.7

30.7

34.7

44.7

sPCB mounting pattern

[Specific No.] –* *, (* *)

(22) :Tin plated embossed tape packaging

(with vacuum pick-up cap)

(52) :Gold plated embossed tape packaging

(with vacuum pick-up cap)

Note:If the pattern is included in the shaded area and

not treated with resist, it could touch the

connector contact .

The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.
