Description

• Medium time delay, low breaking capacity

• Optional axial leads available

• 5mm x 20mm physical size

• Glass tube, nickel-plated brass endcap construction

• Designed to UL/CSA 248-14

Agency Information

• UL Listed, Guide JDYX, File E19180, 63mA-6.3A

• UL Recognized Card: (7A-10A) Guide JDYX2,

File E19180

• CSA Certified, Class 1422-01, File E65063, 63mA-6.3A

• MITI Approval, 1A-10A

• CCC Approval, 500mA-6.3A

Ordering

• Specify packaging, product, and option code

• For -R option, drop mA or A from product code

(i.e. GMC-2-R)

• Ratings above 6.3A have a 0.8mm diameter lead

• With TR2 packaging code, lead wire length is 19.05mm

±

5)

0

0.

5.2mm

(+0.1/-0.2)

38.10mm

0m

(±

±

38)

.3

5.54mm

(±.20)

21.10mm

0

0m

(±. 1)

8

81

0.65mm

(REF)

(±

38.10mm

0mm

0mm

(±. 8)

3

38)

*

Interrupting ratings: Interrupting ratings for 63mA - 6.3A were measured at 70% - 80% power factor on AC. The interrupting ratings for 7A - 10A were measured at 100% power factor on AC.

** DC Cold Resistance (Measured at <10% of rated current)

‡ Maximum Voltage drop (Voltage drop was measured at 20°C ambient temperature at rated current)

ELECTRICAL CHARACTERISTICS

Rated Current % of Amp Rating

Opening Time

100%

None

63mA - 10A

135%

60 minutes maximum

200%

2 minutes maximum

SPECIFICATIONS

Voltage

AC Interrupting

Typical DC Cold

Typical

Maximum

Product Code

Rating

Rating*

Resistance

Voltage

AC

250V

125V

(ohms)**

AC†

Drop (mV)‡

GMC-63mA

250V

35A

10,000A

10.350

0.0027

1400

GMC-80mA

250V

35A

10,000A

-

0.0050

1400

GMC-100mA

250V

35A

10,000A

4.775

0.0094

1200

GMC-125mA

250V

35A

10,000A

3.400

0.014

1000

GMC-150mA

250V

35A

10,000A

2.555

0.022

800

GMC-160mA

250V

35A

10,000A

2.295

0.022

730

GMC-200mA

250V

35A

10,000A

1.395

0.032

650

GMC-250mA

250V

35A

10,000A

0.965

0.046

490

GMC-300mA

250V

35A

10,000A

0.838

0.081

580

GMC-315mA

250V

35A

10,000A

0.685

0.081

480

GMC-400mA

250V

35A

10,000A

0.615

0.18

510

GMC-500mA

250V

35A

10,000A

0.335

0.41

370

GMC-600mA

250V

35A

10,000A

0.282

0.60

360

GMC-630mA

250V

35A

10,000A

0.246

0.66

360

GMC-700mA

250V

35A

10,000A

0.213

0.85

340

GMC-750mA

250V

35A

10,000A

0.213

0.85

320

GMC-800mA

250V

35A

10,000A

0.180

0.85

290

GMC-1A

250V

35A

10,000A

0.156

1.8

250

GMC-1.25A

250V

100A

10,000A

0.098

3.4

200

GMC-1.5A

250V

100A

10,000A

0.076

5.4

190

GMC-1.6A

250V

100A

10,000A

0.067

5.8

160

GMC-2A

250V

100A

10,000A

0.043

8.9

130

GMC-2.5A

250V

100A

10,000A

0.035

13

130

GMC-3A

250V

100A

10,000A

0.026

19

130

GMC-3.15A

250V

100A

10,000A

0.025

23

130

GMC-3.5A

125V

-

10,000A

0.022

25

130

GMC-4A

125V

-

10,000A

0.019

36

120

GMC-5A

125V

-

10,000A

0.014

58

120

GMC-6A

125V

-

10,000A

0.013

88

120

GMC-6.3A

125V

-

10,000A

0.012

110

120

GMC-7A

125V

-

200A

0.012

150

120

GMC-8A

125V

-

200A

0.009

200

110

GMC-10A

125V

-

200A

0.007

300

110

5mm x 20mm Fuses

GMC Series Medium Time Delay, Glass Tube

RoHS

2002/95/EC
