ER3A

B

THRU

ER3

MB

3 Amp Super Fast

Recovery

Silicon Rectifier

50 to

1000 Volts

DO-214AA

(SMB) (LEAD FRAME)

Features

•

Easy Pick And Place

•

High Temp Soldering: 260

°C for 10 Seconds At Terminals

•

Super Fast Recovery Times For High Effieciency

Maximum Ratings

MCC

Catalog

Number

Device

Marking

Maximum

Recurrent

Peak Reverse

Voltage

Maximum

RMS

Voltage

Maximum

DC

Blocking

Voltage

ER3AB

50V

35V

50V

ER3BB

100V

70V

100V

ER3CB

150V

105V

150V

ER3DB

200V

140V

200V

ER3GB

400V

280V

400V

ER3JB

600V

420V

600V

Electrical Characteristics @ 25

°C Unless Otherwise Specified

Average Forward

Current

IF(AV)

3.0A

TA =

75°C

Peak Forward Surge

Current

IFSM

100A

8.3ms, half sine

Maximum

Instantaneous

Forward Voltage

ER3AB-3DB

ER3GB

VF

.95V

1.25V

IFM = 3.0A;

TJ = 25

°C*

Maximum DC

Reverse Current At

Rated DC Blocking

Voltage

IR

5

µA

200

µA

TJ = 25

°C

TJ = 100

°C

Maximum Reverse

Recovery Time

IF=0.5A, IR=1.0A,

Irr=0.25A

Typical Junction

Capacitance

CJ

45pF

Measured at

1.0MHz, VR=4.0V

*Pulse test: Pulse width 300

µsec, Duty cycle 2%

ER3JB~3MB

1.70V

MCC

omponents

20736 Marilla Street Chatsworth

!"#

$% !"#

Revision:

B

20

13/01/01

TM

Micro Commercial Components

www.mccsemi.com

1 of 4

•

Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates

Compliant. See ordering information)

•

Operating Temperature: -50

°C to +150°C

•

Storage Temperature: -50

°C to +150°C

•

Typical

Thermal Resistance; 16

°C/W Junction To Lead

ER3KB

8

00V

56

0V

8

00V

ER3MB

10

00V

700

V

100

0V

1. High Temperature Solder Exemptions Applied, see EU Directive Annex 7.

ER3AB~ER3JB

ER3KB~ER3MB

Trr

35ns

75ns

0.070”

0.090"

0.085”

SUGGESTED SOLDER

PAD LAYOUT

H

J

E

G

A

B

D

C

DIMENSIONS

INCHES

MM

DIM

MIN

MAX

MIN

MAX

NOTE

A

.075

.095

1.91

2.41

B

.077

.083

1.96

2.10

C.002

.008

.05

.20

D

-----

.02

-----

.51

E

.030

.060

.76

1.52

G

.200

.220

5.08

5.59

H

.160

.187

4.06

4.75

J

.130

.155

3.30

3.94

•

Moisture Sensitivity Level 1

•

Epoxy meets UL 94 V-0 flammability rating

•

Halogen free available upon request by adding suffix "-HF"
