2SC4115-R datasheet(1/1 Pages) SECOS

部件名	2SC4115-R

功能描述	NPN Plastic Encapsulated Transistor

PDF	1 Pages

Scroll/Zoom	100%

制造商	SECOS [SeCoS Halbleitertechnologie GmbH]

网页	http://www.secosgmbh.com

标志

1 / 1 page

2SC4115

3A , 40V

NPN Plastic Encapsulated Transistor

Elektronische Bauelemente

20-Mar-2012 Rev. A

Page 1 of 1

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

1

Base

3

Emitter

Collector

2

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

FEATURES

Small Flat Package

General Purpose Application

Low VCE(sat).VCE(sat) = 0.2V (Typ.)(IC / IB = 2A / 0.1A)

CLASSIFICATION OF hFE(1)

Product-Rank

2SC4115-Q

2SC4115-R

2SC4115-S

Range

120~270

180~390

270~560

Marking

4115Q

4115R

4115S

PACKAGE INFORMATION

ABSOLUTE MAXIMUM RATINGS (TA=25°C unless otherwise specified)

Parameter

Symbol

Rating

Unit

Collector-Base Voltage

VCBO

40

V

Collector-Emitter Voltage

VCEO

20

V

Emitter-Base Voltage

VEBO

6

V

Collector Current-Continuous

IC

3

A

Collector Power Dissipation

PC

500

mW

Junction & Storage Temperature

TJ, TSTG

150, -55~150

°C

ELECTRICAL CHARACTERISTICS (TA=25°C unless otherwise specified)

Parameter

Symbol

Min.

Typ.

Max.

Unit

Test conditions

Collector-Base Breakdown Voltage

V(BR)CBO

40

-

V

IC=50µA, IE=0

Collector-Emitter Breakdown Voltage

V(BR)CEO

20

-

V

IC=1mA, IB=0

Emitter-Base Breakdown Voltage

V(BR)EBO

6

-

V

IE=50µA, IC=0

Collector Cut-Off Current

ICBO

-

0.1

µ

A

VCB=30V, IE=0

Emitter Cut-Off Current

IEBO

-

0.1

µ

A

VEB=5V, IC=0

DC Current Gain

hFE

120

-

560

VCE=2V, IC=100mA

Collector-Emitter Saturation voltage

VCE(sat)

-

0.5

V

IC=2A, IB=100mA

Transition Frequency

fT

200

290

-

MHz VCE=2V,IC=500mA,f=100MHz

Package

MPQ

Leader Size

SOT-89

1K

7 inch

SOT-89

A

E

C

D

B

K

H

F

G

L

J

1

2

3

4

B C

E

REF.

Millimeter

REF.

Millimeter

Min.

Max.

Min.

Max.

A

4.40

4.60

G

0.40

0.58

B

3.94

4.25

H

1.50

TYP

C

1.40

1.60

J

3.00

TYP

D

2.25

2.60

K

0.32

0.52

E

1.50

1.85

L

0.35

0.44

F

0.89

1.20
