AISC-0603

OPTIONS AND PART IDENTIFICATION:

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 09.16.13

Visit

ABRACON IS

ISO9001:2008

CERTIFIED

MECHANICAL DIMENSIONS:

Dimension: mm

A MAX.

B MAX.

C MAX.

D REF.

E REF.

F REF.

H REF.

I REF.

J REF.

1.8

1.12

1.02

0.38

0.80

0.30

1.02

0.64

0.64

MATERIALS:

1.80 x 1.12 x 1.02mm

A

Coating

Ultraviolet epoxy resin

c

i

m

a

r

e

C

e

r

o

C

B

C

Wire

Polyurethane system enameled copper wire

D

Electrodes

Ag-Pd with Ni and Au plating

No.

Components

Material

RoHS/RoHS II Compliant

CERAMIC WIRE WOUND INDUCTORS

AISC-0603-

-

Inductance Code

Tolerance

Code

Packaging

Please refer to the Table

C: ± 0.2nH

T: 3kpcs/reel

S: ± 0.3nH

D: ± 0.5nH

G: ±2%

J: ±5%

K: ±10%
