S3A/B - S3M/B

Document number: DS16005 Rev. 16 - 2

2 of 4

www.diodes.com

October 2011

S3A/B - S3M/B

Maximum Ratings @TA = 25°C unless otherwise specified

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitance load, derate current by 20%.

Characteristic

Symbol

A/AB

B/BB

D/DB

G/GB

J/JB

K/KB

M/MB

Unit

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

VRRM

VRWM

100

200

400

600

800

1000

RMS Reverse Voltage

VR(RMS)

140

280

420

560

700

Average Rectified Output Current

@ TT = 75°C

3.0

Non-Repetitive Peak Forward Surge Current 8.3ms

Single Half Sine-Wave Superimposed on Rated Load

IFSM

100

Thermal Characteristics

Characteristic

Symbol

Value

Unit

Typical Thermal Resistance Junction to Terminal

(Note 4)

RθJT

°C/W

Operating and Storage Temperature Range

TJ, TSTG

-65 to +150

°C

Electrical Characteristics @TA = 25°C unless otherwise specified

Characteristic

Symbol

Value

Unit

Forward Voltage

@ IF = 3.0A

VFM

1.15

Peak Reverse Current

@ TA = 25°C

at Rated DC Blocking Voltage

@ TA = 125 °C

IRM

250

µA

Typical Total Capacitance (Note 5)

Notes:

4. Thermal resistance: Junction to Terminal, unit mounted on PC board with 5.0 mm

2 (0.013 mm thick) copper pad as heat sink.

5. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.

1.5

T , TERMINAL TEMPERATURE (ºC)

Fig. 1 Forward Current Derating Curve

0.5

1.0

2.0

2.5

100

125

150

3.0

0.01

0.1

1.0

V , INSTANTANEOUS FORWARD VOLTAGE (V)

Fig. 2 Typical Forward Characteristics

0.4

0.8

1.2

1.6

2.0

I Pulse Width = 300 S
