Inductors for Decoupling Circuits

Multilayer Ferrite

FEATURES

The MLZ Series include inductors for decoupling circuits that have top-class DC superimposition characteristics and low DC resistance.

Sizes range from 1005 to 2012, and they are compatible with wide frequency band noise, from low to high frequency.

H type products have a rated current that is equivalent to that of wound coils.

W type products are the new standard type products that have both large current and low resistance.

L type products have a resistance up to 60% lower than W type products.

APPLICATION

Smart phones, tablet terminals, laptop computers, various modules such as camera modules, DSCs, video games, portable memory

audio devices, navigation systems, PNDs, WLANs, SSDs, automotive equipment (MLZ1608, MLZ2012)

PART NUMBER CONSTRUCTION

OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT

Product compatible with RoHS directive

Halogen-free

Compatible with lead-free solders

AEC-Q200

Overview of the MLZ Series

MLZ

1005

M

R10

W

T

□□□

Series name

L×W×H Dimensions

Product

internal code

Inductance

Characteristic type

Packaging style

Internal code

(mm)

(μH)

1005

1.0×0.5×0.5

A

R10

0.1

H

Ultra-large current type

T

Taping

1608

1.6×0.8×0.8

D

1R0

1

D

High frequency type

2012

2.0×1.25×0.85

M

100

10

W

Large current type

2012

2.0×1.25×1.25

N

L

Low resistance type

P

Type

Temperature range

Package quantity

Individual weight

Operating

Storage

（°C）

（°C）

(pieces/reel)

（mg）

MLZ1005

–55 to +125

–55 to +125

10000

1.2

MLZ1608

–55 to +125

–55 to +125

4000

4

MLZ2012

t=0.85

–55 to +125

–55 to +125

4000

10

t=1.25

2000

14

RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://www.tdk.co.jp/rohs/

Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
