QX-RRD-5M

How to Order

Switch Specifications

Set pressure

PS1000/PS1100

PS1200

t

PS1000 ON

OFF

PS1100 ON

OFF

58 (0.4)

29 (0.2)

0

–14.5 (–0.1)

Set pressure

t

PS1200 ON

OFF

0

–7.25 (–50)

–14.5 (–100)

RoHS

[Option]

Q

R06 L

PS

00

10

Output specifications

10

11

12

For positive pressure

For vacuum and residual pressure

For vacuum

Piping specifications

R06

R07

ø6 reducer

1/4" reducer

L

3 m

Lead wire length

The PS1200 series is CE-

compliant (with Q) only.

Option (CE-compliant )

Nil

Q

None

CE-compliant

Use the pressure setting trimmer to set

ON pressure.

Rotate clockwise to increase the set

pressure. For setting vacuum, rotate

counterclockwise.

To set, use a flat head screwdriver

suited for the groove of the trimmer,

and rotate it lightly with finger tip.

Rotation angle of the trimmer is 220 .

There is a stop provided to prevent the trimmer from rotating beyond its limits.

Rotation beyond the limit can damage the trimmer. Adjust the trimmer gently

within the rotation angle.

+

–

High

pressure

High

vacuum

Pressure setting

trimmer

220

Left end adjustment limit Right end adjustment limit

Setting of Pressure Switch

Trimmer

- +

30

25.5

3000

Pressure setting trimmer

LED indicator

PS1000-R06L

MADE IN JAPAN G

AIRCHECKER

ø6 reducer

1/4" reducer

Dimensions

KQ2H/L/T/S/Y06-M5

KQ2H/L07-M5

Other Series KQ2/KS

Series KJ

Dimensions

A

16

16

13

16

Applicable One-touch fittings

The switch turns ON

when the set

pressure is reached

or exceeded.

The switch turns ON

when at the set

pressure or below.

The switch turns

ON when at the

set pressure or

below.

Addition of PS1200 (For vacuum)

QS

Revision history

Edition B
