RJ45 Network Surge Suppressor for Network/Phone

Lines

MODEL NUMBER: DNET1

Description

Tripp Lite's DNET1 offers network ethernet line surge suppression for 100Base-T, 10Base-T, Token Ring,

AS400/Sys3x and RS422 applications. Convenient RJ45 input and output connections with included 5 inch ethernet patch cable allows convenient placement

at the protected device network connection. Surge suppression is handled with balanced arrays of high-speed avalanche diodes that divert excess energies

created by electrostatic discharges, faulty wiring or lightning away from network interface connections. Tripp Lite network surge suppressors reduce blown NIC

cards, garbled network transmissions, system lock-ups and hard equipment failure by safely shunting dataline surges to ground.

SUPPRESSION: 1 set RJ45 in/out jacks, protects wires 1-8, 7.5V clamping

Features

DNET1 protects network workstations, printers and internetworking devices from surges present on 10/100Base-T, token ring, AS400/Sys3x or RS422

network lines

Convenient RJ45 input and output connections make for simple installation (RJ45 input/output connections, pins 1-8, 7.5V clamping)

5 inch ethernet patch cable enables ideal protection placed as close as possible to the point of use

Surge suppression utilizing high speed avalanche diodes divert excess energies on the network to ground

Specifications

OVERVIEW

Intended Application

Home/Office, Computer Networking

OUTPUT

Circuit Breaker (amps)

750

INPUT

Highlights

Complete Ethernet (RJ45) surge

protection

Protects against the effects of

electrostatic discharge, faulty

wiring and lightning

Applications

Ideal for the protection of network

workstations, printers and other

internetworking devices with a

network Ethernet connection

Ideal for NICs, terminals, hubs,

MAUs, LAN equipment

Package Includes

DNET1 dataline protector

5-in. RJ45 patch cable

Warranty information and

instruction manual
