External battery pack compatibility

BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible)

DC system voltage (VDC)

24

Battery recharge rate (included

batteries)

Less than 9 hours from 10% to 90%

VOLTAGE REGULATION

Voltage regulation description

Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 87 to 140

Overvoltage correction

Input voltages between 127 and 140 are reduced by 12%

Undervoltage correction

Input voltages between 95 and 105 are boosted by 10%

Severe undervoltage correction

Input voltages between 87 and 94 are boosted by 22%

LEDS ALARMS & SWITCHES

LED Indicators

5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status

Alarms

Audible alarm indicates power-failure and low-battery conditions

Alarm cancel operation

Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Switches

2 Switches control off/on power status and alarm-cancel/self-test operation; set of 4 rear-panel switches control

system enable and contact closure port inverter shutoff commands

SURGE / NOISE SUPPRESSION

UPS AC suppression joule rating

720

UPS AC suppression response time

Instantaneous

EMI / RFI AC noise suppression

Yes

AC suppression joule rating

720

AC suppression response time

Instantaneous

PHYSICAL

Installation form factors supported

with included accessories

Tower

Primary form factor

Tower

UPS / Power Module dimensions in

primary form factor (height x width x

depth / inches)

17 x 9 x 12.5

UPS / Power Module dimensions in

primary form factor (height x width x

depth / cm)

43.2 x 22.9 x 31.8

UPS / Power Module weight (lbs)

80

UPS / Power Module weight (kg)

36.3

UPS Shipping dimensions (height x

width x depth / inches)

22.2 x 12.8 x 16.5
