ECNR

Class RK5 250Vac, 1 to 60A

Dual-Element, Time-Delay Fuses

Form No. ECNR 1-60

Page 2 of 2

Data Sheet #1315

0509

BU-SB08624

Current Limitation Curves

Time-Current Characteristic Curves–

Average Melt

Time-Current Characteristic Curves–

Average Melt

The only controlled copy of this document is the electronic read-only version maintained by Cooper Bussmann. All other copies of this document are by

definition uncontrolled. This bulletin is intended to clearly present comprehensive product data and provide technical information that will help the end

user with design applications. Cooper Bussmann reserves the right, without notice, to change design or construction of any products and to

discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any technical information

contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.

8 10 15

30

60

Fuse Reducers For Class R Fuses

Equipment

Desired Fuse

Catalog Number

Fuse Clips

(Case) Size

(Pairs) 250V

60A

30A

No. 263-R

100A

30A

No. 213-R

60A

No. 216-R

200A

60A

No. 226-R
