MicroSmart Series

Programmable Logic Controllers

I/O Modules Speciﬁcations

Input Module

Part Number

FC4A-N08B1

FC4A-N16B1

FC4A-N16B3

FC4A-N32B3

FC4A-N08A11

Input Points

8 (8/1 common)

16 (16/1 common)

32 (16/1 common) 8 (4/1 common)

Input Voltage

24V DC sink/source input signal

100 to 120V AC (50/60 Hz)

Input Voltage Range

20.4 to 28.8V DC

85 to 132V AC

Input Current

7mA/point (24V DC)

5mA/point (24V DC)

17mA/point (120V AC, 60 Hz)

Input Impedance

3.4kΩ

4.4kΩ

0.8kΩ (60 Hz)

ON Voltage

15V minimum

9V minimum

OFF Voltage

5V maximum

20V maximum

ON Current

4.2mA minimum (at 15V DC)

3.2mA minimum (at 15V DC)

—

OFF Current

1.2mA maximum

0.9mA maximum

—

Turn ON Time

4ms

25ms

Turn OFF Time

4ms

30ms

Isolation

Between input terminals: Not isolated

Internal circuit: Photocoupler isolated

Between input terminals in the same common: Not isolated

Between input terminals in different commons: Isolated

Between input terminals and internal circuits: Photocoupler

isolated

External Load for I/O

Interconnection

Not needed

Single Determination Method

Static

Effect of Improper Input

Connection

Both sink and source input signals can be connected. If any input exceeding

the rated value is applied, permanent damage may be caused.

If any input exceeding the rated value is applied, permanent

damage may be caused.

Cable Length

3m in compliance with electromagnetic immunity

—

Connector on Mother Board

MC1.5/10-G-3.81BK (Phoenix Contact)

FL26A2MA (Oki Electric Cable)

MC1.5/10-G-3.81BK (Phoenix Contact)

Connector Insertion/

Removal Durability

100 times minimum

Applicable Ferrule

1-wire: A1 0.5-8 WH

2-wire: A1-TWIN 2×0.5-8 WH

——

Internal

Current

Draw

All Inputs ON

25mA (5V DC)

40mA (5V DC)

35mA (5V DC)

65mA (5V DC)

60mA (5V DC), 0mA (24V DC)

All Inputs OFF

5mA (5V DC)

10mA (5V DC)

30mA (5V DC), 0mA (24V DC)

Internal Power Consumption

(at 24V DC while all inputs ON)

0.17W

0.27W

0.24W

0.44W

—

Weight

85g

100g

65g

100g

80g

Transistor Output Modules

Part Number

FC4A-T08K1

FC4A-T08S1

FC4A-T16K3

FC4A-T16S3

FC4A-T32K3

FC4A-T32S3

Output Points

8 (8/1 common)

16 (16/1 common)

32 (16/1 common)

Output

FC4A-T®K®: Transistor sink output

FC4A-T®S®: Transistor source output

Load Voltage

24V DC

Operating Load Voltage

Range

20.4 to 28.8V DC

Maximum Load Current

0.3A per point

0.1A per point

3A per common

1A per common

Voltage Drop (ON Voltage)

1V maximum (voltage between COM and output terminals

when output is on)

Inrush Current

1A maximum

Clamping Voltage

39V±1V

Maximum Lamp Load

Inductive Load

L/R = 10ms (28.8V DC)

External Current Draw

FC4A-T®K®: 100mA maximum,

24V DC (power voltage at the +V terminal)

FC4A-T®S®: 100mA maximum,

24V DC (power voltage at the –V terminal)

Isolation

Between output terminal and internal circuit:

Photocoupler isolated

Between output terminals: Not isolated

Part Number

FC4A-T08K1

FC4A-T08S1

FC4A-T16K3

FC4A-T16S3

FC4A-T32K3

FC4A-T32S3

Connector on Mother

Board

MC1.5/10-G-

3.81BK

(Phoenix

Contact)

FL26A2MA (Oki Electric Cable)

Connector Insertion/

Removal Durability

100 times minimum

Applicable Ferrule

1-wire: A1 0.5-8 WH

2-wire: A1-TWIN 2×0.5-8 WH

Internal

Current

Draw

All outputs ON

10mA (5V DC)

20mA (24V DC)

10mA (5V DC)

40mA (24V DC)

20mA (5V DC)

70mA (24V DC)

All outputs

OFF

5mA (5V DC)

0mA (24V DC)

5mA (5V DC)

0mA (24V DC)

10mA (5V DC)

0mA (24V DC)

Internal Power

Consumption (at 24V DC

while all outputs ON)

0.55W

1.03W

1.82W

Output

Delay

Turn ON Time

300μs maximum

Turn OFF Time

300μs maximum

Weight

85g

70g

105g
