Overview

Industrial Panel

Computers &

Monitors

Heavy-duty

Fanless Touch

Panel Computers

Digital Signage

Solutions

Healthcare

& Medical

Solutions

Open Frame

Panel

Computers

Accessories

1

Ordering Information

Specifications

Optional Accessories

Optional OS Installation

Dimensions

I/O Connector

1 x RS-232/422/485 (isolated 4KV)

2 x 10/100/1000Mbps Ethernet

2 x USB 2.0 (isolated 4KV)

2 x USB 3.0

1 x Audio (Line-out)

1 x Audio (Mic-in)

1 x DisplayPort

Expansion Interface

1 x PCI or 1 x PCIe x4 slot (optional)

2 x PCIe Mini Card slot

Speaker

2 x 2W

Camera

1 x 5M pixels camera

Touchscreen

5-wire resistive type

Function Key

LCD brightness up/down, audio volume up/down, power on/off

Power Supply

External 24VDC with AC/DC medical grade power adapter

Dimensions

438 mm (17.24") (W) x 76.5 mm (3.01") (D) x 376.4 mm

(14.81") (H)

Packing Dimensions

610 mm (24.02") (W) x 260 mm (10.24") (D) x 590 mm (23.23") (H)

Weight (net/gross)

10.35 kg (22.81 lb)/ 11.9 kg (26.23 lb)

Environment

Operating temperature: 0°C ~ +40°C (+32°F ~ +104°F)

Storage temperature: 0°C ~ +40°C (+32°F ~ +104°F)

Relative humidity: 20% ~ 90% @ 40°C; non-condensing

Certificate

CE

IFO2175-873

17" TFT 3rd Gen Intel® Core™ i7/i5/i3 & Celeron®

processor fanless panel computer with resistive T/S, PCIe or

PCI expansion or Super Multi drive

* Specification and certifications are based on options and may vary.

**Super Multi drive includes DVD-R, DVD-RW and DVD-RAM.

E202003330

VM-101 VESA ARM (clamp type)

E202003329

VM-105 VESA ARM (wall mount type)

E228170100

17" stand kit

Windows® XP

Windows® 7

Windows® 8.1

WE8S

438

75

100

76.5

OPEN I/O COVER VIEW
