SMD Type

www.kexin.com.cn

1

Transistors

NPN Transistors

2SD965

■

Features

●

Low Collector-Emitter Saturation Voltage

●

Large Collector Power Dissipation and Current

●

Mini Power Type Package

1.Base

2.Collector

3.Emitter

1.70 0.1

0.42 0.1

0.46 0.1

■

Absolute Maximum Ratings Ta = 25℃

Parameter

Symbol

Rating

Unit

Collector - Base Voltage

VCBO

40

Collector - Emitter Voltage

VCEO

20

Emitter - Base Voltage

VEBO

7

Collector Current - Continuous

IC

5

A

Collector Power Dissipation

PC

750

mW

Thermal Resistance From Junction To Ambient

RθJA

167

℃

/W

Junction Temperature

TJ

150

Storage Temperature Range

Tstg

-55 to 150

V

℃

■

Electrical Characteristics Ta = 25℃

Parameter

Symbol

Test Conditions

Min

Typ

Max

Unit

Collector- base breakdown voltage

VCBO

Ic= 100 μA， IE= 0

40

V

Collector- emitter breakdown voltage

VCEO

Ic= 1 mA， IB= 0

20

Emitter - base breakdown voltage

VEBO

IE= 100μA， IC= 0

7

Collector-base cut-off current

ICBO

VCB= 10 V , IE= 0

100

nA

Emitter cut-off current

IEBO

VEB= 7V , IC=0

100

Collector-emitter saturation voltage

VCE(sat) IC=3 A, IB=100mA

1

V

Base - emitter saturation voltage

VBE(sat) IC=3 A, IB=100mA

1.2

hFE(1)

VCE= 2V, IC= 1mA

200

hFE(2)

VCE= 2V, IC= 500mA

230

950

hFE(3)

VCE= 2V, IC= 2A

150

Collector output capacitance

Cob

VCB= 20V, IE= 0,f=1MHz

50

pF

Transition frequency

fT

VCE= 6V, IC= 50mA,f=200MHz

150

MHz

DC current gain

■

Classification of hfe(2)

Type

2SD965-Q

2SD965-R

2SD965-S

2SD965-T

Range

230-380

340-600

560-800

560-950

Marking

965Q

965R

965S

965T
