AD8250

Data Sheet

Rev. C | Page 10 of 24

–5

–10

–15

–40 –25 –10

110 125

IB–

IB+

IOS

TEMPERATURE (°C)

Figure 18. Input Bias Current and Offset Current vs. Temperature

140

120

100

10k

100k

FREQUENCY (Hz)

G = 10

G = 5

G = 2

G = 1

Figure 19. CMRR vs. Frequency

140

120

100

10k

100k

FREQUENCY (Hz)

G = 10

G = 5

G = 2

G = 1

Figure 20. CMRR vs. Frequency, 1 kΩ Source Imbalance

–10

–8

–6

–4

–2

–50

–30

–10

110

130

TEMPERATURE (°C)

Figure 21. CMRR vs. Temperature, G = 1

–10

–5

10k

100k

10M

100M

FREQUENCY (Hz)

G = 10

G = 5

G = 2

G = 1

Figure 22. Gain vs. Frequency

–10

–30

–20

–40

–10

–8

–6

–4

–2

2468

OUTPUT VOLTAGE (V)

f = 1kHz

Figure 23. Gain Nonlinearity vs. Output Voltage, G = 1, RL = 10 kΩ, 2 kΩ, 600 Ω
