0

INPUT OVERDRIVE (mV)

0

204060

60

50

40

30

20

10

80

100

LH NON INV

LH INV

HL NON INV

HL INV

Figure 24. Propagation Delay vs. Input Overdrive

CH3 5.00V

CH2 5.00V

M20.0µs

CH1

7mV

2

3

1

NON INV (OUTA)

INV (OUTB)

Figure 25. Noninverting and Inverting Comparators Propagation Delay

0.01

OUTPUT PULL-UP RESISTOR (kΩ)

1

0.1

1

100

10

10

0.1

100

1000

RISE

FALL

Figure 26. Rise and Fall Times vs. Output Pull-Up Resistor

CH2 500mV

2

1

OUTA

R1 = 22kΩ

R2 = 2.2kΩ

R3 = 6.2kΩ

M100ms

Figure 27. Hysteresis Programmed to ~513 mV at Top of Input String

(Hysteresis at ADCMP341 Pins ≈ 104 mV)
