Supports activate self-test and UPS output power control for delayed or immediate reboot of connected equipment

Diagnostic LEDs (indicate 17 performance conditions)

Specifications

OUTPUT

Output Capacity Details

2400W maximum output with up to 1 external battery pack connected; 1600W maximum capacity with 2-3 external

battery packs connected; 1250W maximum capacity with 4 or more external battery packs connected

Output Volt Amp Capacity (VA)

3000

Output kVA Capacity (kVA)

3

Output Watt Capacity (Watts)

2400

Output kW Capacity (kW)

2.4

Power Factor

0.8

Nominal Output Voltage(s)

Supported

120V

Frequency Compatibility

60 Hz

Output Voltage Regulation (Line

Mode)

-13% / +5%

Output Voltage Regulation (Battery

Mode)

+/- 5%

Output Receptacles

(4) 5-15R; (4) 5-15/20R

Load Management Receptacles

Two switchable single-outlet 5-15R load banks

Output Circuit Breakers

15A branch rated (x2) - each breaker protects 4 outlets

Output AC Waveform (AC Mode)

Sine wave

Output AC Waveform (Battery Mode)

PWM sine wave

INPUT

Rated input current (Maximum Load)

22A

Nominal Input Voltage(s) Supported

120V AC

UPS Input Connection Type

L5-30P

UPS Input Cord Length (ft.)

8

UPS Input Cord Length (m)

2.4

Recommended Electrical Service

30A 120V

Input Phase

Single-Phase

BATTERY

Full Load Runtime (min.)

7 min. (2400w)

Half Load Runtime (min.)

23 min. (1200w)

2 / 4
