21.11.2011

LED535-series

2 of 8

Type

Viewing

Half Angle

Outer

Dimension

Dimension

Figure

[Unit: mcd]

[Unit: mW/sr]

Typ.

Typ.

LED535-01

±8°

9500

14

Ø 5

1

LED535-02

±5°

10000

16

Ø 5

2

LED535-03

±10°

10000

15

Ø 5

3

LED535-04

±20°

3800

6

Ø 5

4

LED535-05

±50°

530

1

Ø 5

5

LED535-06

±4°

11000

18

Ø 5

6

LED535-09

±25° (long)

6000

9

Ø 5

7

±10° (short)

Oval

LED535-46

Ø 5

8

LED535-41

±14°

6700

10

Ø 4

9

LED535-42

±20°

3800

5.5

Ø 4

10

LED535-31

Ø 3

11

LED535-33

±13°

4800

7

Ø 3

12

LED535-34

Ø 3

13

LED535-36

±25°

1800

3.5

Ø 3

14

* Radiant Power is measured by S3584-08

* Brightness is measured by TekTronix J-16

The above specifications are for reference purpose only and subjected to change without prior notice.

Outer Dimensions

Figure-1 Ø 5Mold (Type 01)

Figure-2 Ø 5Mold (Type 02)

Figure-3 Ø 5Mold (Type 03)

Figure-4 Ø 5Mold (Type 04)
