LED910-series

2 of 8

Type

Viewing

Half Angle

Outer

Dimension

Dimension

Figure

[Unit: mW/sr]

Typ.

LED910-01AU

±10°

70

Ø 5

1

LED910-02AU

±7°

70

Ø 5

2

LED910-03AU

±10°

70

Ø 5

3

LED910-04AU

±20°

20

Ø 5

4

LED910-05AU

±40°

7

Ø 5

5

LED910-06AU

±7°

65

Ø 5

6

LED910-09AU

±25° (long)

35

Ø 5

7

±15° (short)

Oval

LED910-46AU

Ø 5

8

LED910-41AU

±16°

32

Ø 4

9

LED910-42AU

±23°

17

Ø 4

10

LED910-31AU

Ø 3

11

LED910-33AU

±18°

25

Ø 3

12

LED910-34AU

Ø 3

13

LED910-36AU

±33°

15

Ø 3

14

* Radiant Power is measured by Photodyne #500

* Brightness is measured by TekTronix J-16

The above specifications are for reference purpose only and subjected to change without prior notice.

Outer Dimensions

Figure-1 Ø 5Mold (Type 01)

Figure-2 Ø 5Mold (Type 02)

Figure-3 Ø 5Mold (Type 03)

Figure-4 Ø 5Mold (Type 04)
