littelfuse.com

Rev: 063014

10 of 10

LIVE PARTS

TRIPLE BARREL

Bottom Lever In

Closed Position

.56 Dia. (2) Holes

For Mounting

Cable/Bus

.44 DIA. (2) HOLES

DOUBLE BARREL

SINGLE BARREL

1.75

1.00

2.00

2.00

2.00

4.9

4.85

3.63

3.63

3.75

Top Lever in

Open Position

A

Blown Fuse

Indicator

TOP

VIEW

4.50

3.08

1.50

4.16

0.38" HOLES

.78

.63

.08

.30

.31

.08

.71

1.15

.05

.78

Description

Live parts are available for mounting E, R, and PT single, double, and triple barrel

fuses. Mounting clips are available for ferrule type and clip lock style fuses.

All clips are sold in pairs.

Part Number 700-520-CL

Ordering Number 0700520.ZXCL

Clip Lock Design

Part Number 700-530

Ordering Number 0700530.Z

For use with all 3" diameter fuses.

Dimensions for reference only.

Part Number 700-500

Ordering Number 0700500.Z

Part Number 700-156

Ordering Number 0700156.Z

Part Number 700-300

Ordering Number 0700300.Z

For use with 3” diameter fuses.

2.85

Mounting Hole

Dimension

2.00

3.74

1.00

Dimensions in inches

Dimensions in inches

Mounting Details for Clip Lock

CATALOG NUMBER

DIMENSION A (INCHES)

10E1CL5.5 thru 150E1CL5.5

12.88

225E2CL5.5 thru 600E3CL5.5

13.88

10E1CL8.25 thru 350E3CL8.25

13.88

10E1CL15.5 thru 50E1CL15.5

16.25

65E1CL15.5 thru 300E3CL15.5

19.25
