AFCP-R4X25PL-Series

4x25Gb/s ROSA for 100 Gigabit Ethernet

Product Brief

Description

Avago Technologies’ AFCP-R4X25PL-Series ROSA is

a 4x25Gb/s, 1310nm LAN WDM receive optical sub-

assembly, containing an optical de-multiplexer, to

separate the four incoming wavelengths, four high

reliability, high performance PIN photodiodes, and

a quad transimpedance amplifier (TIA). These are

packaged in an hermetic, planar package with an LC

receptacle. The electrical interface is via two flex cir-

cuits. The ROSA is intended for use in CFP, CFP2 and

CFP4 modules serving links at 4 x 25.78125 Gb/s, per

100GBASE-LR4.

Features

• Integrated 1:4 optical de-multiplexer/ filter

• Four high reliability, high performance PIN

detectors

• Transimpedance amplifier (TIA) array

• 25.78125 Gb/s per channel operation

- Capable of 27.952Gb/s operation

• Planar body compatible with CFP, CFP2 and CFP4

• Flex circuit electrical interface

• LAN WDM Wavelengths
