IMX2

DUAL TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R215-004.D

PARAMETER

SYMBOL

RATING

UNIT

Collector-Base Voltage

60

V

Collector-Emitter Voltage

50

V

Emitter-Base Voltage

7

V

Collector Current

150

mA

Collector Power Dissipation

300 (Note1)

mW

Junction Temperature

150

°C

Storage Temperature

-55~+150

°C

Note: 1. 200mW per element must not be exceeded.

2. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Collector-Base Breakdown Voltage

60

V

Collector-Emitter Breakdown Voltage

50

V

Emitter-Base Breakdown Voltage

7

V

Collector Cut-Off Current

0.1

µA

Emitter Cut-Off Current

0.1

µA

Collector-Emitter Saturation Voltage

0.4

V

DC Current Transfer Ratio

120

560

Transition Frequency (Note)

180

MHz

Output Capacitance

2

3.5

pF

Note: Transition frequency of the device.
