29/06/2011 V5.0

1

Features:

> High brightness surface mount LED using thin film technology.

> 120° viewing angle.

> Small package outline (LxWxH) of 3.2 x 2.8 x 1.8mm.

> Qualified according to JEDEC moisture sensitivity Level 2.

> Compatible to IR reflow soldering.

> Environmental friendly; RoHS compliance.

Synonymous with function and performance, the DomiLED

perfectly suited for a variety of cross-industrial applications due to its

small package outline, durability and superior brightness.

DATA SHEET:

Colored Resin : DRx-RJE

© 2005 DomiLED is a trademark of DOMINANT Opto Technologies.

All rights reserved. Product specifications are subject to change without notice.

Applications:

> Automotive: interior applications, eg: switches, telematics,

climate control system, dashboard, etc.

> Consumer appliances: LCD illumination as in PDAs, LCD TV.

> Communication: indicator and backlight in mobilephone.

> Display: full color display video notice board.

> Industrial: white goods (eg: Oven, microwave, etc.).

DOMINANT

Opto Technologies

Innovating Illumination

TM
