DESCRIPTION

Power supply can deliver 90W continuous output power.

High efficiency & compact dimension with an IEC 320/C 8

(FSP090RDC M1) or IEC 320/C 6 (FSP090-RDBM1) inlet to

mate with interchangeable cord for world-wide use.

APPLICATION

Display, Electrocardiogram (EC G), Respirator

FEATURES

Input voltage range 85~264Vac

Slim design 140 * 71 * 22 mm

High altitude 5000M operation

Meet EN 55011 / EN 55022 and FC C class B emission

OVP, OC P, OTP protection

C ompliant with Energy Star efficienct level V

* No load power consumption less than 0.5W

* Avergy active efficiency greater than 87%

Optional output connectors

W ATTAGE

Wattage:

90W

DIMENSION

Dimension:

140mm(L) x 71mm(W) x

22mm(H)

INPUT SPECIFICATION

Input Range:

90-264 Vac

Input F requency :

7-63 Hz

Leakage Current:

100 uA @ 264Vac / 63 Hz

SAFETY STANDARD APPAOVAL

ENVIRONMENTAL SPECIFICATION

TEMP.Range:

Operating Temperature:0°C to

+40°C

Storage Temperature: -20°C to +

Humidity :

Operating : 5% to 95% RH, Non-

condensing

OUTPUT ELECTRICAL

Single Output:

18 V/ 5 A

Line Regulation:

+/- 1%

Load Regulation:

+/- 5%

T his co nte nt is subje ct to cha nge , ple a se re fe r to spe cifica tio n fo r m o re de ta il.

FSP re se rve the right to cha nge the co nte nt witho ut prio r no tice

Medical PSU

FSP090-RDCM1 / FSP090-RDCM1
