CSMS0620D Series

SMD WIRE WOUND POWER INDUCTORS (SHIELDED)

Rev. A

A. Electrical Specifications:

P/N

Marking

Inductance

@100KHz

(μH)

Inductance

Tolerance

DCR

±20%

(Ω)

Rated Current (mA)

SRF Min.

(MHz)

I sat

I rms

CSMS0620D-R80N

0R8

0.8

± 30%

0.020

6400

4100

110

CSMS0620D-1R5N

1R5

1.5

± 30%

0.026

4300

3600

93

CSMS0620D-2R2N

2R2

2.2

± 30%

0.034

3200

2900

73

CSMS0620D-3R3N

3R3

3.3

± 30%

0.040

2800

2750

55

CSMS0620D-4R7N

4R7

4.7

± 30%

0.058

2400

2150

43

CSMS0620D-6R8N

6R8

6.8

± 30%

0.085

2000

1800

30

CSMS0620D-100M

100

10

± 20%

0.125

1900

1500

18

CSMS0620D-220M

220

22

± 20%

0.290

1250

950

11

B. Dimensions: mm (Inch)

Series

a

b

c

d

e

f

g

h

i

k

m

n

CSMS0620D

6.0

(0.236)

6.0

(0.236)

2.0

(0.079)

1.35

(0.053)

2.3

(0.091)

4.0

(0.157)

4.8

(0.189)

0.3

(0.012)

1.6

(0.063)

5.2

(0.205)

5.7

(0.224)

4.7

(0.185)

Tol.

±0.2

(0.008)

±0.2

(0.008)

Max.

±0.2

(0.008)

Typ.

±0.2

(0.008)

Typ.

Typ.

Typ.

Typ.

Typ.

Typ.

C. General Information:

1. CSMS0620D-xxx_, “CSMS0620D” = P/N, “xxx” = Inductance, “_” = Tolerance.

2. Tolerance “_”: M: ± 20%, N: ± 30%

3. Magnetically shielded

4. High saturation current

5. Storage temperature: -40ºC to +85ºC.

6. Operating temperature range: -25ºC to +125ºC (Including self-heating).

7. Inductance measured using the HP4285A and Chroma1320 & 3302.

8. DCR measured using Chroma 16502.

9. SRF measured using the HP4291B.

10. Saturation Current Idc1: The value of current causes a 30% Inductance reduction from initial value. ( at : 20 ºC ambient)

11. Temperature rise current Idc2: The value of current causes a 40ºC temperature rise. ( at : 20 ºC ambient)

12. Rated Current: Either Idc1 or Idc2 whichever is smaller.

13. MSL: Level 1.

14. Inductance and Current range: From 0.8 µH (4100mA) to 22.0 µH (950mA).

D. Applications:

1. Game Consoles

2. Set Top Boxes

3. Cables Modems

4. Computers

5. Mobile Communication Devices (Cell Phones, Radios, etc.)

6. PDA, LCD, DVD, BRP, HD.
