background image
JH24240320A
VER: 0.1
- 11 -
Issue date: 2013/08/01
JEWEL HILL ELECTRONIC CO.,LTD.
7.INTERFACE DESCRIPTION.
Pin NO.
Symbol
Description
1
GND
Power Ground
2
VCI
The
power supply 2.8V
3
VDD
The
power supply 2.8V
4
CS
CHIP SELECT PIN
5
RS
Command/display data select pin
6
/WR/SCL
Write enable clock input pin
7
RD
Read enable clock input pin
8
SDI
Serial data input pin
9~26
D0~D17
Data Bus
27
ENABLE
A data ENABLE signal in RGB I/F mode
28
DOTCLK
Data enable signal in RGB interface
29
HSYNC
Horizontal synchronizing signal in RGB interface
30
VSYNC
Vertical synchronizing signal in RGB interface
31
RESET
Reset Pin
32
IM3
Interface Mode Select
33
IM2
Interface Mode Select
34
IM1
Interface Mode Select
35
IM0
Interface Mode Select
36
LED_A
LED+
37
LED_K1
LED-
38
LED_K2
LED-
39
LED_K3
LED-
40
LED_K4
LED-
41
SDO
NC
42
XL
TOUCH PANEL X_ LEFT
43
YU
TOUCH PANEL Y_ UP
44
XR
TOUCH PANEL X_ RIGHT
45
YD
TOUCH PANEL Y_ DOWN
