10 / 26 page  JH30240400B VER: 0.1 - 9 - Issue date: 2013/08/01 JEWEL HILL ELECTRONIC CO.,LTD. 4.3 Interface Signals Pin NO. Symbol Description 1 LCM-ID TBD 2 XL Touch Panel connection(NC) 3 YU Touch Panel connection(NC) 4 XR Touch Panel connection(NC) 5 YD Touch Panel connection(NC) 6 GND Ground 7 IOVCC A Power Supply For The Internal Logic(1.65-3.3V) 8 VCC A Power Supply For The Internal Logic:Vcc=2.8V 9 FMARK Frame Head Pulse Signal 10 CS LCD Chip Select Input Pin 11 RS Reg Selection For Command/Data 12 WR Write Execution Control Pin 13 RD Read Execution Control Pin 14-29 DB0-DB15 Data Bus 30 RESET Reset Pin 31 NC No Connect 32 A Backlight Anode 33 K1 Backlight Cathode1 34 K2 Backlight Cathode2 35 K3 Backlight Cathode3 36 K4 Backlight Cathode4 37 K5 Backlight Cathode5 |
|
|
