- Ketone

- Aromatic solvents

Wipe off saliva or water drops immediately, contact with water over a long period of

time may cause deformation or color fading. Avoid contacting oil and fats.

(7) Exercise care to minimize corrosion of the electrode. Corrosion of the electrodes is

accelerated by water droplets, moisture condensation or a current flow in a

high-humidity environment.

(8) Install the LCD Module by using the mounting holes. When mounting the LCD module

make sure it is free of twisting, warping and distortion. In particular, do not forcibly pull

or bend the I/O cable or the backlight cable.

(9) Do not attempt to disassemble or process the LCD module.

(10) NC terminal should be open. Do not connect anything.

(11) If the logic circuit power is off, do not apply the input signals.

(12) Since LCM has been assembled and adjusted with a high degree of precision, avoid

applying excessive shocks to the module or making any alterations or modifications

to it.

- Do not alter, modify or change the shape of the tab on the metal frame.

- Do not make extra holes on the printed circuit board, modify its shape or change

the positions of components to be attached.

- Do not damage or modify the pattern writing on the printed circuit board.

- Absolutely do not modify the zebra rubber strip (conductive rubber) or heat seal

connector.

- Except for soldering the interface, do not make any alterations or modifications with

a soldering iron.

- Do not drop, bend or twist LCM.

Storage Precautions.

When storing the LCD modules, the following precaution is necessary.

(1) Store them in a sealed polyethylene bag. If properly sealed, there is no need for the

dessicant.

(2) Store them in a dark place. Do not expose to sunlight or fluorescent light, keep the

temperature between 0°C and 35°C.

(3) The polarizer surface should not come in contact with any other objects. (We advise

you to store them in the container in which they were shipped).
