JH4667201280A

VER: 1.0

- 3 -

Issue date: 2013/08/15

JEWEL HILL ELECTRONIC CO.,LTD.

1. GENERAL DESCRIPTION.

JH4667201280A model is a Color TFT LCD. This main Module has a 4.66 inch

diagonally measured active display area with 720(RGB)×1280 resolution. Each pixel is

divided into Red, Green and Blue sub-pixels and dots which are arranged in vertical stripes.

The LCD color is determined with 16.7M colors signal for each pixel.

The JH4667201280A has been designed to apply the interface method that enables low

power, high speed, and high contrast.

JH4667201280A is intended to support applications where thin thickness, wide viewing

angle and low power are critical factors and graphic displays are important.

2. GENERAL FEATURES.

Item

Display Panel

Remark

Display Mode

Normally White, Transmissive LCD

Viewing Direction

Full view

Input Signals

MIPI

Outside Dimensions

61.91(W)*114.38(H)*1.55(N)

Effective Area

-

Active Area

58.1mm(W)×103.3mm(H)

Number of Pixels

720×RGB×1280Pixels

Pixel Pitch

0.0807mm(H)×0.0807mm(W)

Pixel Arrangement

RGB Vertical stripes

Drive IC

NT35590

3.Absolute Maximum Ratings

The following are maximum values which, if exceeded may cause operation or damage to

the unit.

ITEM

Symbol

Min.

Typ.

Max.

Unit

Remark

Power for Circuit Driving

VDD

-0.3

-

5.5

V

Power for Circuit Logic

VCI

-0.3

-

5.5

V

LC Operating Voltage *1)

Vop

-

V

LED Forward Voltage

29.0

30.0

31.0

V

LED Forward Current

If

-

15

-

mA

LED Luminance

4000

-

-

Storage Humidity

10

-

90

%RH

Storage Temperature

T

BBBBBBBBB

ST

BBBBBBBBB

-30

-

80

℃

Operating Ambient Humidity

H

BBBBBBBBB

OP

BBBBBBBBB

10

-

90

%RH

Operating Ambient temperature

T

BBBBBBBBB

OP

BBBBBBBBB

-20

-

70

℃

At

25±5℃
