32kHz

<10MHz

10 ~ 20MHz

>20 ~ 160MHz

300μA

2mA

3mA

25mA

1mA

4mA

5mA

30mA

2mA

6mA

7mA

40mA

CMOS Oscillator -55+125°C

MCSO2

17 Dec 2015

2011/65/EU

Open

‘1’ level

‘0’ level

Enabled

Enabled

High Impedance

Ordering Information

DD

Features

Specifications

* Frequency stability is inclusive of calibration @ 25°C, operating temperature range, sup-

ply voltage change, load change and ageing over 10 years.

Enable / Disable Function

Input (pad 1)

Output (pad 3)

Option

Codes

MCSO2

Product

Parameters

MCSO2:  10.0kHz ~ 20.0MHz

MCSO2H:  20.0 ~ 225MHz

Frequency range:10.0kHz ~ 225MHz



Supply voltage (V

+5.0V (±5%)



+3.3V (±5%)



V

+2.5V (±5%)



W

Frequency stability*:

±100ppm



±50ppm



T

tighter stabilities on request



specify

Operating temperature range:

0 to +70°C



A

-40 to +85°C



B

-55 to +125°C



C

Storage temperature range:

-55 to +125°C



Supply current:

See table

Driving ability:

CMOS



Load:

3pF min, 47pF max



Logic levels:

‘0’ level = +0.4V max



‘1’ level = V



Start up time:

5ms max



Waveform symmetry:

40:60 max @ 50%V

DD



Rise / fall times:

7ns max ≤20MHz



3ns max >20MHz







150ns max@ 32.768kHz



Enable / disable function:

None (pad 1 NC)



Tristate* (control via pad 1)



E

* not available under 500kHz

Shock resistance:

5,000G, 0.3ms, ½ sine



Vibration resistance:

20G rms 10.0 ~ 2,000Hz



Soldering condition:

260°C, 10 sec max



Product name + option codes + frequency

For frequencies 20.0MHz add an 'H' to the product name

Option code X (eg MCSO2/X) denotes a custom specification.

Supply current

Freq / Supply

2.5V

3.3V

5.0V

Maximum values, no load.

12

43

TOP VIEW

5.00

±0.01

3.20

±0.01

1.70

(max)

2.35

1.60

1.00

1.60

1.00

1.50

1.50

2.70

SOLDER PAD LAYOUT

12

43
