1 / 2 page

E3DB

E3GB

ES3ABF THRU ES3JBF

Reverse Voltage - 50 to 600 Volts

Forward Current - 3.0 Amperes

Note:1.Reverse recovery condition IF=0.5A,IR=1.0A,Irr=0.25A

2.Measured at 1MHz and applied reverse voltage of 4.0V D.C.

3.P.C.B. mounted with 0.5x0.5

”(12.7x12.7mm) copper pad areas

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

VOLTS

SYMBOLS

UNITS

Amps

Volts

VRRM

VRMS

VDC

I(AV)

IFSM

VF

3.0

100

1.25

Operating junction and storage temperature range

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward rectified current

at TL=100 C

Peak forward surge current

8.3ms single half sine-wave superimposed on

rated load (JEDEC Method)

Maximum instantaneous forward voltage at 3.0A

Maximum DC reverse current

TA=25 C

at rated DC blocking voltage

TA=125 C

IR

5.0

100.0

R

θJA

CJ

TJ,TSTG

55.0

45.0

-55 to +150

pF

C

A

µ

Typical thermal resistance (NOTE 3)

C/W

Typical junction capacitance (NOTE 2)

Maximum reverse recovery time

(NOTE 1)

trr

35

ns

ES3ABF

ES3BBF

ES3DBF

ES3GBF

ES3JBF

Ratings at 25 C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.

50

35

50

100

70

100

200

140

200

400

280

400

600

420

600

MDD Catalog Number

Dimensions in inches and (millimeters)

SMBF

Cathode Band

Top View

0.165(4.2)

0.173(4.4)

0.216(5.5)

0.200(5.1)

0.146(3.70)

0.138(3.50)

0.075(1.90)

0.086(2.20)

0.051(1.30)

0.043(1.10)

0.010(0.26)

0.0071(0.18)

0.051(1.30)

0.039(1.0)

FEATURES

For surface mounted applications

Low profile package

Glass Passivated Chip Junction

Superfast reverse recovery time

Lead free in comply with EU RoHS 2011/65/EU diretives

MECHANICAL DATA

Case: JEDEC SMBF molded plastic body

Terminals: leads solderable per MIL-STD-750,

Method 2026

Mounting Position: Any

Weight:57mg/0.002oz

Marking code

E3AB

E3BB

E3JB

1.7

1.0

SURFACE MOUNT SUPERFAST RECOVERY RECTIFIER
