B158

s Single Row Straight Pin Header

[Specific No.] –* *, (* *)

Blank: Tin plated

(01) : Gold plated

s Single Row Right Angle Pin Header

[Specific No.] –* *, (* *)

Blank: Tin plated

(01) : Gold plated

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.) If needed, please order the product per bag.

Note 2.The 2 and 3 contact connector contains the concave portion to prevent miss-insertion in the center at one point, which is

different from the above figure.In addition, the 4 to 7 contact connectors have two concave portions at both ends.

Unit: mm

Part Number

CL No.

DF1B-11P-2.5DSA(**)

DF1B-12P-2.5DSA(**)

DF1B-13P-2.5DSA(**)

DF1B-14P-2.5DSA(**)

DF1B-15P-2.5DSA(**)

DF1B-16P-2.5DSA(**)

DF1B-18P-2.5DSA(**)

DF1B-20P-2.5DSA(**)

541-0234-8-**

541-0235-0-**

541-0236-3-**

541-0237-6-**

541-0238-9-**

541-0239-1-**

541-0240-0-**

541-0241-3-**

11

12

13

14

15

16

18

20

25

27.5

30

32.5

35

37.5

42.5

47.5

30

32.5

35

37.5

40

42.5

47.5

52.5

Number of Contacts

A

B

Part Number

CL No.

DF1B- 2P-2.5DSA(**)

DF1B- 3P-2.5DSA(**)

DF1B- 4P-2.5DSA(**)

DF1B- 5P-2.5DSA(**)

DF1B- 6P-2.5DSA(**)

DF1B- 7P-2.5DSA(**)

DF1B- 8P-2.5DSA(**)

DF1B- 9P-2.5DSA(**)

DF1B-10P-2.5DSA(**)

541-0225-7-**

541-0226-0-**

541-0227-2-**

541-0228-5-**

541-0229-8-**

541-0230-7-**

541-0231-0-**

541-0232-2-**

541-0233-5-**

2

3

4

5

6

7

8

9

10

2.5

5

7.5

10

12.5

15

17.5

20

22.5

7.5

10

12.5

15

17.5

20

22.5

25

27.5

Number of Contacts

A

B

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Note 2.The 4 and 6 contact connector contains the concave portion to prevent miss-insertion in the center at one point, which is

different from the above figure.

Unit: mm

Part Number

CL No.

DF1B-11P-2.5DS(**)

DF1B-12P-2.5DS(**)

DF1B-13P-2.5DS(**)

DF1B-14P-2.5DS(**)

DF1B-15P-2.5DS(**)

DF1B-16P-2.5DS(**)

DF1B-18P-2.5DS(**)

DF1B-20P-2.5DS(**)

541-0251-7-**

541-0252-0-**

541-0253-2-**

541-0254-5-**

541-0255-8-**

541-0256-0-**

541-0257-3-**

541-0258-6-**

11

12

13

14

15

16

18

20

25

27.5

30

32.5

35

37.5

42.5

47.5

30

32.5

35

37.5

40

42.5

47.5

52.5

Number of Contacts

A

B

Part Number

CL No.

DF1B- 2P-2.5DS(**)

DF1B- 3P-2.5DS(**)

DF1B- 4P-2.5DS(**)

DF1B- 5P-2.5DS(**)

DF1B- 6P-2.5DS(**)

DF1B- 7P-2.5DS(**)

DF1B- 8P-2.5DS(**)

DF1B- 9P-2.5DS(**)

DF1B-10P-2.5DS(**)

541-0242-6-**

541-0243-9-**

541-0244-1-**

541-0245-4-**

541-0246-7-**

541-0247-0-**

541-0248-2-**

541-0249-5-**

541-0250-4-**

2

3

4

5

6

7

8

9

10

2.5

5

7.5

10

12.5

15

17.5

20

22.5

7.5

10

12.5

15

17.5

20

22.5

25

27.5

Number of Contacts

A

B
