B172

sSingle Row Crimping Plug

[Specific No.] – **, (**)

Blank: 1 bag: 100pcs.

(40): 500pcs. packaging

(41): 1000pcs. packaging

Photo: Contact insertion state.

+0

+0.1

Unit:mm

CL No.

Part Number

544-0003-4-**

544-0004-7-**

544-0005-0-**

544-0006-2-**

544-0007-5-**

544-0008-8-**

544-0009-0-**

DF4- 2P-2C (**)

DF4- 3P-2C (**)

DF4- 4P-2C (**)

DF4- 5P-2C (**)

DF4- 6P-2C (**)

DF4- 7P-2C (**)

DF4- 8P-2C (**)

Number of Contacts

2

3

4

5

6

7

8

A

B

10.5

12.5

14.5

16.5

10.0

12.0

14.0

CL No.

Part Number

544-0010-0- **

544-0011-2- **

544-0012-5- **

544-0013-8- **

544-0014-0- **

544-0015-3- **

544-0016-6- **

DF4- 9P-2C (**)

DF4-10P-2C (**)

DF4-11P-2C (**)

DF4-12P-2C (**)

DF4-13P-2C (**)

DF4-14P-2C (**)

DF4-15P-2C (**)

Number of Contacts

10

11

12

13

14

15

A

B

18.5

20.5

22.5

24.5

26.5

28.5

30.5

16.0

18.0

20.0

22.0

24.0

26.0

28.0

Note 1.The quantity at the specific No. "None" is delivered per bag (100pcs.). If needed, please order the products per bag.

sCrimping Contact

Part Number

CL No.

Packaging Type

Quantity

Finish

DF4-2428PCF

544-0020-3

Reel

10,000

Tin plating

DF4-2428PC

544-0021-6

Bag

100

Tin plating

qApplicable Cable (Tin plating Annealed copper wire)

Note:If other cables are used instead of the applicable cable, contact Hirose sales

department.

q Strip Length: 1.3 to 1.9mm

BApplicable Crimping Tool

Type

Part Number

CL No.

Applicable Contact

Applicator

AP105-DF4-2428P

901-4539-0

DF4-2428PCF

Press Main Unit

CM-105

901-0005-4

–––––––

Manual Crimping Tool DF4-TA2428HC

550-0173-6

DF4-2428PC

Extraction Tool

DF-C-PO (B)

550-0179-2

DF4-2428PCF

Note: If any trouble has occurred due to other tools, which are not designated by Hirose,

Hirose won't guarantee any products.

Conductor Size

Recommended Cable

Jacket Diameter

AWG24 (11 cores./0.16mm)

UL1061

AWG 26 (7cores./0.16mm)

Ø0.75 to Ø1.2mm

AWG 28 (7cores./0.127mm)

UL1061/1007
