A271

sReceptacle (SMT)

Note1: Please order the tube packaging products, multiplying a tube quantity ( pcs.).

Note2: The 40 contacts connector is marchandized only in combination with the SMT product.

Unit: mm

Part Number

CL No.

DF11- 4DS-2V(**)

DF11- 6DS-2V(**)

DF11- 8DS-2V(**)

DF11-10DS-2V(**)

DF11-12DS-2V(**)

DF11-14DS-2V(**)

DF11-16DS-2V(**)

DF11-18DS-2V(**)

DF11-20DS-2V(**)

DF11-22DS-2V(**)

DF11-24DS-2V(**)

DF11-26DS-2V(**)

DF11-28DS-2V(**)

DF11-30DS-2V(**)

DF11-32DS-2V(**)

DF11-40DS-2V(**)

543-0569-9-**

543-0570-8-**

543-0571-0-**

543-0572-3-**

543-0573-6-**

543-0574-9-**

543-0575-1-**

543-0576-4-**

543-0577-7-**

543-0578-0-**

543-0579-2-**

543-0580-1-**

543-0581-4-**

543-0582-7-**

543-0583-0-**

543-0584-2-**

4

6

8

10

12

14

16

18

20

22

24

26

28

30

32

40

2.0

4.0

6.0

8.0

10.0

12.0

14.0

16.0

18.0

20.0

22.0

24.0

26.0

28.0

30.0

38.0

8.5

10.5

12.5

14.5

16.5

18.5

20.5

22.5

24.5

26.5

28.5

30.5

32.5

34.5

36.5

44.5

Number of Contacts

A

B

4.5

6.5

8.5

10.5

12.5

14.5

16.5

18.5

20.5

22.5

24.5

26.5

28.5

30.5

32.5

40.5

C

8.7

10.7

12.7

14.7

16.7

18.7

20.7

22.7

24.7

26.7

28.7

30.7

32.7

34.7

36.7

44.7

D

41pcs.

35

30

27

24

22

20

18

17

16

15

14

13

12

12

10

Tube Package Quantity

BPCB mounting pattern

BTube Size

[Specific No.] –* *, (* *)

(20) :Tin plated tube package product

(50) :Gold plated tube package product

Note:If the pattern is included in the shaded area and

not treated with resist, it could touch the

connector contact .
