background image
53
sConversion adapters
qFC / SC
qFC / SC
sReceptacle
Part Number
CL No.
Split sleeve
HSCJ-HRFCJ-B(51)
704-0021-3-51
Copper alloy
Part Number
HRS No.
Remarks
HRFC-R1
701-0016-4
MM
HRFC-R2
701-0023-0
SM
BPanel Cutout
2--M8∞0.75
Ø9
+0.5
0
13.4±0.1
2--M2∞0.4
13.4
9
21.2
5.5
12.2
3.5
or 2--Ø2.4 +0.2
0
M8∞0.75
5.5
M9.5
M15
4- Ø2.2
3
9
Ø4 Countersink depth 1.5
9.5±0.1
Ø9
+0.5
0
4--M2∞0.4
or 4--Ø2.4 +0.2
0
BPanel Cutout
qFC / SC
M8∞0.75
27.9
21
(1.8)
7.4
9.4
CL No.
Part Number
Polishing type Fiber type
704-0203-0-51
HSCP-HRFCJ-1(51)
PC
GI-50/125
704-0288-3-51
HSCP-HRFCJ-1AS(51)
AdPC
704-0204-3-51
HSCP-HRFCJ-2(51)
PC
SM-9.5/125
704-0289-6-51
HSCP-HRFCJ-2AS(51)
AdPC
Split sleeve
Copper alloy
CL No.
Part Number
Polishing type Fiber type
701-0065-0-51
HRFCP-HSCJ-1(51)
PC
GI-50/125
701-0108-0-51
HRFCP-HSCJ-1AS(51)
AdPC
701-0085-7-51
HRFCP-HSCJ-2(51)
PC
SM-9.5/125
701-0109-3-51
HRFCP-HSCJ-2AS(51)
AdPC
Split sleeve
Copper alloy
13.7
32
(3.9)
12.8
9
Board thiekness : 16mm
