A274

sIn-line Plug

BIn-line Plug Panel Cutouts

Note1: Please use the non-radius side for the panel hooking area.

Note2: Applicable panel thicknessing is 1.6 to 1.0mm (A slight deviation will occur for the thickness except for 1.6 and 1.2mm.)

Photo: Contact insertion status

Part Number

CL No.

Unit: mm

DF11- 4DEP-2C(**)

DF11- 6DEP-2C(**)

DF11- 8DEP-2C(**)

DF11-10DEP-2C(**)

DF11-12DEP-2C(**)

DF11-14DEP-2C(**)

DF11-16DEP-2C(**)

DF11-18DEP-2C(**)

DF11-20DEP-2C(**)

DF11-22DEP-2C(**)

DF11-24DEP-2C(**)

DF11-26DEP-2C(**)

DF11-28DEP-2C(**)

DF11-30DEP-2C(**)

DF11-32DEP-2C(**)

543-0619-5-**

543-0620-4-**

543-0621-7-**

543-0622-0-**

543-0623-2-**

543-0624-5-**

543-0625-8-**

543-0626-0-**

543-0627-3-**

543-0628-6-**

543-0629-9-**

543-0630-8-**

543-0631-0-**

543-0632-3-**

543-0633-6-**

4

6

8

10

12

14

16

18

20

22

24

26

28

30

32

11.0

13.0

15.0

17.0

19.0

21.0

23.0

25.0

27.0

29.0

31.0

33.0

35.0

37.0

39.0

9.2

11.2

13.2

15.2

17.2

19.2

21.2

23.2

25.2

27.2

29.2

31.2

33.2

35.2

37.2

Number of Contacts

A

B

6.0

8.0

10.0

12.0

14.0

16.0

18.0

20.0

22.0

24.0

26.0

28.0

30.0

32.0

34.0

C

2.0

4.0

6.0

8.0

10.0

12.0

14.0

16.0

18.0

20.0

22.0

24.0

26.0

28.0

30.0

D

9.4

11.4

13.4

15.4

17.4

19.4

21.4

23.4

25.4

27.4

29.4

31.4

33.4

35.4

37.4

E

6.3

8.3

10.3

12.3

14.3

16.3

18.3

20.3

22.3

24.3

26.3

28.3

30.3

32.3

34.3

F

Note1: The specific No. "Blank" item is delivered per bag unit (100 pcs.). Please order products per bag unit.

[Specific No.] –* *, (* *)

Blank

:100 pcs. per pack
