(3/11)

INDUC

T

O

RS

20150310 / inductor_commercial_standard_mlf2012_en.fm

Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

Inductors for Standard Circuits

Multilayer Ferrite

FEATURES

The lineup includes a wide inductance range.

Highly reliable monolithic structure with multilayer integration.

APPLICATION

Smart phones, tablet terminals, tuners, LCD-TVs, PDP-TVs, audio equipment, computers, signal processing for modules etc.

PART NUMBER CONSTRUCTION

OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT

Product compatible with RoHS directive

Halogen-free

Compatible with lead-free solders

Overview of MLF2012 Type

MLF

2012

D

47N

△

T000

Series name

L×W×H Dimensions

characteristics

Inductance

Inductance

tolerance

Packaging style

Internal code

(mm)

(μH)

2012

2.0×1.25×0.85

A

10N

0.010

(10nH)

J

±5%

T

Taping

000

2.0×1.25×1.25

C

K

±10%

D

R10

0.1

M

±20%

E1R0

1

K

100

10

Type

Package quantity

Individual weight

Operating

temperature

（°C）

Storage

（°C）

(pieces/reel)

（mg）

MLF2012

t=0.85

–55 to +125

–55 to +125

4,000

10

t=1.25

2,000

14

RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/

Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
