LightKey

SPEC NO: DS10121745

REV: A.4

CHECKED: Emily Zhou

APPROVED: M.H. Lin

PAGE: 2/3

HTTP://WWW.DISPLAY-LEDS.COM

TEL: 0086-574-86322282

DATE: Jul/20/2011

Datasheet of 2.00 inch Single Digit 16 Segment LED Display

Internal Circuit Diagram

Selection Guide

Single Digit 16 Segment LED Display, Digit Height: 50.80mm(2.00inch), External Dimensions:

45.00x65.00x11.00mm (L x W x H )

Part No.

Chip

One Seg

One Seg

A,D,G,H,K,L or DP

Common

Cathode

Common

Anode

Material

Color

WLD

Min.

Typ.

Min.

Typ.

LD20011CR

LD20011DR

GaAlAs

Super Red

640

48

60

24

30

LD20011CD

LD20011DD

GaAlAs

Hi-Red

640

108

150

54

75

LD20011CO

LD20011DO

GaAlAs

Orange

625

42

54

21

27

LD20011CY

LD20011DY

GaAlAs

Yellow

588

48

60

24

30

LD20011CG

LD20011DG

GaP

Green

568

42

54

21

27

LD20011CUR

LD20011DUR

AlGaInP

Ultra Red

640

180

270

90

135

LD20011CUO

LD20011DUO

AlGaInP

Ultra Orange

625

270

360

135

180

LD20011CUA

LD20011DUA

AlGaInP

Ultra Amber

605

180

270

90

135

LD20011CUY

LD20011DUY

AlGaInP

Ultra Yellow

595

180

270

90

135

LD20011CUG

LD20011DUG

AlGaInP

Ultra Green

573

180

270

90

135

LD20011CPG

LD20011DPG

InGaN

Pure Green

525

720

1800

360

900

LD20011CUB

LD20011DUB

InGaN

Ultra Blue

470

180

270

90

135

LD20011CUW

LD20011DUW

SMD

Ultra White

\

600

720

300

360

Unit:

\

\

\

nm

mcd

mcd

mcd

mcd
