LBV330-XXBNDRANX1900 | LBV300

LEVEL SENSORS

Illustration may differ

Ordering information

Type

Part no.

LBV330-XXBNDRANX1900

6038285

Other models and accessories

www.sick.com/LBV300

Detailed technical data

Features

Medium

Bulk solids

Measurement

Switch

Probe length

1,900 mm

Process pressure

–1 bar ... 25 bar

Process temperature

–50 °C ... +250 °C

Fill material density

≥ 0.008

Particle size

< 10 mm

Performance

Accuracy of sensor element

± 10 mm

Repeatability

≤ 5 mm

Response time

500 ms when covered / 1,000 ms when uncovered

Electronics

Power consumption

5 mA ... 30 mA

Initialization time

< 2 s

VDE protection class 1

✔

Electrical connection

½" NPT

Supply voltage

Double relay (DPDT): 20 V DC ... 72 V DC / 20 V AC ... 253 V AC

Hysteresis

10 mm

Output current

> 10 µA; < 3A AC, 1A DC

Inductive load

750 VA 54 W

Capacitive load

750 VA 54 W

Contact load

Min. 50 mW / max. 750 VA, 54 W

Enclosure rating

IP 66 / IP 67

Mechanics

Process connection

1 1/2" NPT PN 25 / stainless steel 316L

Housing material

Aluminum

Sensor material

Stainless steel 1.4404

2

FLUID SENSORS | SICK

Online data sheet | 2016-05-17 16:55:06

Subject to change without notice
