Surface Mount Multilayer Ceramic Chip Capacitors (SMD MLCCs)

HV-HT Series, High Voltage, High Temperature 200°C, C0G Dielectric, 500 – 2,000 VDC (Industrial Grade)

Benefits

• Operating temperature range of −55°C to +200°C

• Lead (Pb)-Free, RoHS, and REACH compliant

• EIA 0805, 1206, 1210, 1808, 1812, 1825, 2220, 2225, 2824,

3040, 3640 and 4540 case sizes

• DC voltage ratings of 500 V, 630 V, 1 KV, 1.5 KV, and 2 KV

• Capacitance offerings ranging from 1 pF to 0.150 μF

• Available capacitance tolerances of ±0.10 pF, ±0.25 pF,

±0.5 pF, ±1%, ±2%, ±5%, ±10%, and ±20%

• No piezoelectric noise

• Extremely low ESR & ESL

• High thermal stability

• High ripple current capability

• No capacitance change with respect to applied rated

DC voltage

• Negligible capacitance change with respect to temperature

from −55°C to +125°C

• No capacitance decay with time

• Non-polar device, minimizing installation concerns

• 100% pure matte tin-plated termination finish allowing for

excellent solderability

• SnPb plated termination finish option available upon request

(5% Pb minimum)

• Gold (Au), Tin/Lead (Sn/Pb) and 100% pure matte Tin (Sn)

termination finishes available

Applications

Typical applications include critical timing, tuning, circuits requiring low loss, circuits with pulse, high current, switch mode power

supplies (input filters, resonators, tank circuits, snubbed circuits, output filters), high voltage coupling, DC blocking and voltage

multiplier circuits in extreme environments such as down-hole exploration, aerospace engine compartments and geophysical probes.

Markets include power supply, HID lighting, industrial equipment/control, automotive, aerospace, and munitions.

Qualification/Certification

High temperature (200ºC) Industrial grade products meet or exceed the requirements outlined in Table 4, Performance & Reliability.

Qualification packages are available for review and download on our website at www.kemet.com/hightemp

Environmental Compliance

Lead (Pb)-Free, RoHS, and REACH compliant without exemptions (excluding SnPb termination finish option).
