50W Single Output Switching Power Supply

WWW.ASTRODYNETDI.COM

ASTRODYNE USA: 1-800-823-8082

ASTRODYNE PACIFIC: 886-2-26983458

Universal AC input

Protections:Short circuit/Over load/Over voltage

Cooling by free air convection

LED indicator for power on

Small and compact size

Built-in remote ON-OFF control

Low profil: 23mm thickness

Model Number Output Volts Output Amps

Ripple & Noise Min Load DC Volt Adjust Peak Load Volt Tolerance

SINGLE OUTPUT

LPS50-3.3

3.3 Volts(DC)

10 Amps

50mV pk-pk

0~12Amps

3~3.6Volt(DC)

39.6W

±3.0%

LPS50-5

5 Volts(DC)

10 Amps

50mV pk-pk

0~12Amps

4.5~5.5Volt(DC)

60W

±3.0%

LPS50-12

12 Volts(DC)

4.2 Amps

80mV pk-pk

0~5.0Amps

10.8~13.2Volt(DC)

60W

±2.0%

LPS50-15

15 Volts(DC)

3.4 Amps

80mV pk-pk

0~4.1Amps

13.5~16.5Volt(DC)

61.5W

±2.0%

LPS50-24

24 Volts(DC)

2.1 Amps

80mV pk-pk

0~2.5Amps

21.6~27.2Volt(DC)

60W

±1.0%

LPS50-48

48 Volts(DC)

1.1 Amps

100mV pk-pk

0~1.3Amps

43.2~52.8Volt(DC)

62.4W

±1.0%
