ECONOLINE

DC/DC-Converter

with 3 year Warranty

REC6/R

Refer to Application Notes

Features

Regulated

Converters

6 Watt DIP24

Reinforced

Output

Selection Guide

Part

Input

Output

Output

Efficiency

Max

Number

Voltage

Voltage

Current

Capacitive

DIP24

(VDC)

(VDC)

(mA)

(%)

REC6-xx05SRW/R*

9 - 18, 18 - 36, 36 - 75

5

1000

80, 81, 82

6800µF

4.5 - 9

77

REC6-xx09SRW/R*

9 - 18, 18 - 36, 36 - 75

9

667

81, 82, 83

6800µF

4.5 - 9

555

80

REC6-xx12SRW/R*

9 - 18, 18 - 36, 36 - 75

12

500

82, 83, 84

6800µF

4.5 - 9

417

82

REC6-xx15SRW/R*

9 - 18, 18 - 36, 36 - 75

15

400

84, 85, 86

6800µF

4.5 - 9

333

83

REC6-xx24SRW/R*

9 - 18, 18 - 36, 36 - 75

24

250

83, 84, 85

4700µF

4.5 - 9

208

82

REC6-xx05DRW/R*

9 - 18, 18 - 36, 36 - 75

±5

±500

80, 81, 82 ±2200µF

4.5 - 9

77

REC6-xx09DRW/R*

9 - 18, 18 - 36, 36 - 75

±9

±335

81, 82, 83 ±2200µF

4.5 - 9

±278

80

REC6-xx12DRW/R*

9 - 18, 18 - 36, 36 - 75

±12

±250

81, 82, 83 ±2200µF

4.5 - 9

±208

82

REC6-xx15DRW/R*

9 - 18, 18 - 36, 36 - 75

±15

±200

82, 83, 84 ±2200µF

4.5 - 9

±167

80

R* = R8 or R10 for 8kVDC or 10kVDC isolation.

Note 1: Maximum capacitive load is defined as the capacitive load that will allow start up in under 1 second

without damage to the converter.

The REC6 series uses a reinforced isolation transformer to offer exceptionally high isolation of

8kVDC (4kVAC/1 minute) or 10kVDC (5kVAC/1minute) making it suitable for HT monitoring cir-

cuits, mains power meters, IGBT isolated power supplies and other sophisticated industrial and

medical applications. The isolation capacitance of only 20pF makes them also suitable for low

leakage applications. The isolation transformer is recognized by CSA as reinforced isolated with

a minimum internal clearance of 2.4mm and a minimum internal creepage clearance of 4.6mm.

The REC6 is available in two industry-standard pinouts (= "/A" or "/C"). Remote on/off con-

trol is possible with the /CTRL option (A pinning only) and an optional undervoltage lockout

function is also available (="/X1"). The converters can deliver 140% rated power for short pe-

riods of time to cope with applications with large capacitive loads or high start up currents.

Description

2:1 Input

(REC6-S_DRW/R8(R10)

xx = 4.5-9Vin = 05

xx = 9-18Vin = 12

xx = 18-36Vin = 24

xx = 36-75Vin = 48

* add suffix "/A" or "/C" for pinning options, see next page for details.

* add suffix “/CTRL” for control pin option (A Pinning only)

* add suffix "/X1" for Undervoltage Lockout

Ordering Examples:

REC6-0512DRW/R8/A/CTRL= 5V Vin, ±12V Vout, 8kVDC isolation, pinout “A”,control pin

REC6-4805SRW/R10/A = 48V Vin, 5V Vout, 10kVDC isolation, pinout “A”

REC6-1212DRW/R8/C/X1 = 12V Vin, ±12V Vout, 8kVDC isolation, pinout “C”,UVL

REC6-0505SRW/R10/A/CTRL/X1 = 5V Vin, 5V Vout, 10kVDC isolation, pinout “A”,control pin, UVL

Derating-Graph

(Ambient Temperature)

120

100

20

60

125

75

0

-40

Operating Temperature (°C)

0

80

50

25

85

40

105

Safe Operating Area

C22.2-No. 60950 Certified

C22.2-601.1 Certified

UL-60601.1 Certified

E-314885

RoHS

2011/65/EU

6/6

REV: 0/2015

E-153
