Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.

Should a safety concern arise regarding this product, please be sure to contact us immediately.

Conductive Polymer Aluminum Solid Capacitors

+

–

L

R

W

0.2 max.

Lot. No.

Polarity marking (−)

Series

R. Capacitance

R. Voltage

Surface Mount Type

Features

Size code

B6

C6

E7

E12

F12

Category temperature range

–55 °C to +105 °C

Rated voltage range

16 V.DC to 25 V.DC

16 V.DC to 50 V.DC

Rated capacitance range

27 μF to 82 μF

10 μF to 180 μF

18 μF to 270 μF

39 μF to 560 μF

68 μF to 1000 μF

Capacitance tolerance

±20 % (120 Hz / + 20 °C)

Leakage current

Please see the attached characteristics list

Dissipation factor (tan

d)

Please see the attached characteristics list

Endurance

+105 °C, 5000 h, rated voltage applied

Capacitance change

Within ±20 % of the initial value

tan d

< 150 % of the initial limit

DC leakage current Within the initial limit

Damp heat

(Steady State)

+60 °C, 90 % to 95 %, 1000 h, No-applied voltage

Capacitance change

Within ±20 % of the initial value

tan d

< 150 % of the initial limit

DC leakage current Within the initial limit (after voltage processing)

Marking

Unit : mm

Size

L

+0.1

W±0.2 H±0.2 C±0.2

R

P±0.2

B6

5.0

5.9

5.3

5.3

6.0

0.6 to 0.8

1.4

C6

6.3

5.9

6.6

6.6

7.3

0.6 to 0.8

2.1

E7

8.0

6.9

8.3

8.3

9.0

0.6 to 0.8

3.2

E12

8.0

11.9

8.3

8.3

9.0

0.8 to 1.1

3.2

F12

10.0

12.6

10.3

10.3

11.0 0.8 to 1.1

4.6

−0.4

Specifications

Dimensions (not to scale)

✽ Externals of figure are the reference.

Nov. 2015

01
