Wire Wound Inductor - Ceramic Or Ferrite Base

|||||||||| | | | | |

AISC-1008(F)

2.92 x 2.79 x 2.29m m

ABRACON IS

ISO 9001 / QS 9000

CERTIFIED

ABRACON IS

ISO 9001 :2008

CERTIFIED

30332 Esperanza, Rancho Santa Margarita, California92688

Visit www.abracon.com for Terms & Conditions of Sale

Revised: 09.17.13

Part Number

AISC-1008F-

Inductance Code

Inductance

Tolerance

Min.

Quality

Factor

L/Q Test

Freq.

Max. DC

Resistance

Max. Rated

Current

Min. Self-resonant

Frequency

Units

nH

-

-

MHz

Ω

mA

MHz

Symbol

L

-

Q

Freq.

DCR

Ir

S.R.F

AISC-1008F-R33

330

J, K, M

50

25/100

0.17

700

600

AISC-1008F-1R0

1,000

J, K, M

20

7.9/50

0.80

600

250

AISC-1008F-1R2

1,200

J, K, M

37

7.9/50

0.80

650

250

AISC-1008F-1R5

1,500

J, K, M

35

7.9/50

0.76

630

190

AISC-1008F-1R8

1,800

J, K, M

33

7.9/50

0.84

600

170

AISC-1008F-2R2

2,200

J, K, M

30

7.9/50

1.15

520

150

AISC-1008F-2R7

2,700

J, K, M

25

7.9/50

1.30

490

120

AISC-1008F-3R3

3,300

J, K, M

23

7.9/50

1.70

450

100

AISC-1008F-3R9

3,900

J, K, M

26

7.9/25

2.00

420

100

AISC-1008F-4R7

4,700

J, K, M

31

7.9/7.9

1.68

400

60

AISC-1008F-5R6

5,600

J, K, M

23

7.9/7.9

2.65

380

80

AISC-1008F-6R8

6,800

J, K, M

20

7.9/7.9

3.00

360

60

AISC-1008F-8R2

8,200

J, K, M

20

7.9/7.9

3.30

330

40

AISC-1008F-100

10,000

J, K, M

15

7.9/7.9

2.95

300

40

Test Conditions and Equipemt

b. Relative Humidity: 65%±20%

c. Air Pressure: 86KPa to 106KPa

Inductance (L): Agilent4287A+Agilent16197A or equivalent, -13dBm or 10mA

Direct Current Resistance (DCR): HIOKI 3540 or equivalent

Q Factor (Q): Agilent4287A+Agilent16197A or equivalent, -13dBm or 10mA

Self-Resonant Frequency (SRF): Agilent4991B+Agilent16197A and HP 8753E or equivalent, -20dBm or

50mV

chip initial surface temperature (Ta)

Operating Temperature: -40ºC to +125ºC for AISC-1008, -40ºC to +85ºC for AISC-1008F

Storage Temperature: -10ºC to +40ºC, 70% RH max.
