1 / 2 page

ES3JB

ES3GB

ES3DB

ES3CB

ES3BB

ES3AB

ES3AB - ES3JB

ES3EB

1 of 2

VOLTAGE RANGE: 50 - 600V

SURFACE MOUNT SUPER FAST RECOVERY DIODES

!

Glass Passivated Die Construction

!

Low Forward Voltage Drop, High Efficiency

!

Plastic Case Material has UL Flammability

!

Terminals: Solder Plated, Solderable

per MIL-STD-750, Method 2026

!

Polarity: Cathode Band or Cathode Notch

!

Marking: Type Number

!

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

VRRM

VRWM

VR

50

100

150

200

300

400

600

V

RMS Reverse Voltage

VR(RMS)

35

70

105

140

210

280

420

V

Average Rectified Output Current

@TL = 75°C

IO

3.0

A

Non-Repetitive Peak Forward Surge Current

8.3ms Single half sine-wave superimposed on

rated load (JEDEC Method)

IFSM

100

A

Forward Voltage

@IF = 3.0A

VFM

0.95

1.25

1.7

V

Peak Reverse Current

@TA = 25°C

At Rated DC Blocking Voltage

@TA = 100°C

IRM

5.0

500

µA

Reverse Recovery Time (Note 1)

trr

35

nS

Typical Junction Capacitance (Note 2)

Cj

45

pF

Typical Thermal Resistance (Note 3)

RJL

16

°C/W

Operating and Storage Temperature Range

Tj, TSTG

-65 to +150

°C

Note: 1. Measured with IF = 0.5A, IR = 1.0A, Irr = 0.25A. See figure 5.

2. Measured at 1.0 MHz and applied reverse voltage of 4.0 V DC.

3. Mounted on P.C. Board with 8.0mm2 land area.

Classification Rating 94V-O

Super-Fast Recovery Time

Low Power Loss

Ideally Suited for Automatic Assembly

Features

Mechanical Data

Case: SMB/DO-214AA, Molded Plastic

CURRENT: 3.0 A

Characteristic

Symbol

Unit

Weight: 0.093 grams (approx.)

Maximum Ratings and Electrical Characteristics TA = 25°C unless otherwise specified

Single phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.

SMB(DO-214AA)

Dim

Min

Max

A

B

C

1.91

2.21

D

0.15

0.31

E

5.00

5.59

G

0.10

0.20

H

0.76

1.52

J

2.00

2.62

All Dimensions in mm

A

B

C

D

G

H

E

J

3.30

3.94

4.06

4.70

A

B

C

D

G

H

E

J

www.sunmate.tw
