1 / 2 page

Unit

US3MB

US3KB

US3JB

US3GB

US3AB - US3MB

US3DB

US3BB

US3AB

Case: SMB/DO-214AA, Molded Plastic

VOLTAGE RANGE: 50 - 1000V

!

Glass Passivated Die Construction

!

Low Forward Voltage Drop, High Efficiency

!

Plastic Case Material has UL Flammability

!

Terminals: Solder Plated, Solderable

per MIL-STD-750, Method 2026

!

Polarity: Cathode Band or Cathode Notch

!

Marking: Type Number

!

Low Power Loss

Classification Rating 94V-O

Ideally Suited for Automatic Assembly

Ultra-Fast Recovery Time

CURRENT: 3.0 A

50

35

50

100

70

100

200

140

200

400

280

400

600

420

600

800

560

800

V

A

V

VRRM

VRMS

VDC

I(AV)

IFSM

VF

3.0

100.0

Operating junction and storage temperature range

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward rectified current

0.375”(9.5mm) lead length at TA=55 C

Peak forward surge current

8.3ms single half sine-wave superimposed on

rated load (JEDEC Method)

Maximum instantaneous forward voltage at 3.0A

Maximum DC reverse current

TA=25 C

at rated DC blocking voltage

TA=100 C

IR

5.0

250.0

R JL

CJ

TJ,TSTG

15.0

-65 to +150

pF

C

T

C/W

Typical junction capacitance (NOTE 2)

Maximum reverse recovery time

(NOTE 1)

trr

50

75

ns

1000

700

1000

1.0

1.70

Note:1.Reverse recovery condition IF=0.5A,IR=1.0A,Irr=0.25A

2.Measured at 1MHz and applied reverse voltage of 4.0V D.C.

1.30

75

θ

µA

Maximum Ratings and Electrical Characteristics TA = 25°C unless otherwise specified

Single phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.

Features

Mechanical Data

Weight: 0.093 grams (approx.)

ypical thermal resistance

SURFACE MOUNT ULTRA FAST RECTIFIER DIODES

Characteristic

Symbol

SMB(DO-214AA)

Dim

Min

Max

A

B

C

1.91

2.21

D

0.15

0.31

E

5.00

5.59

G

0.10

0.20

H

0.76

1.52

J

2.00

2.62

All Dimensions in mm

A

B

C

D

G

H

E

J

3.30

3.94

4.06

4.70

A

B

C

D

G

H

E

J

1 of 2

www.sunmate.tw
