ASPI-2010HC

ELECTRICAL SPECIFICATIONS:

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 01.07.13

Visit www.abracon.com for Terms & Conditions of Sale

FEATURES:

APPLICATIONS:

• Smart Phone, Tablet, Notebook, Desktop, Server

• Blu-Ray Disc Recorder, Set Top Box

• Portable Gaming Device, Navigation Device

2.0 x 1.6 x 1.0 mm

ABRACON IS

ISO9001:2008

CERTIFIED

OPTIONS AND PART IDENTIFICATION

Wire Wound Magnetically Shielded SMD Power Inductor (High Current)

Abracon P/N:

ASPI-2010HC

Storage Temperature & Humidity:

• Iron based core provides large saturation current

• Low DCR lowers power loss

• Magnetic-resin shielding reduces leakage flux and

Electro Magnetic Interference (EMI)

• Metal core designed for excellent shock resistance

• Low profile package takes up little PCB space

-40˚C ~ +125˚C (including self heating)

-10˚C ~ +40˚C and 70% R.H. max. (In tape and reel)

Part Number

ASPI-2010HC-

Inductance Code

Inductance

Inductance

Tolerance

DC Resistance

Max

Min. Self

Resonant

Frequency

Saturation

Current Typ

Saturation

Current Max

Temperature

Rise Current

Typ

Temperature

Rise Current

Max

Units

μH

%

Ω Max

MHz

A Typ

A Max

A Typ

A Max

Symbol

L

M

SRF Min

Isat

Irms

ASPI-2010HC-R24

0.24

M

0.040

145

5.50

4.50

3.45

3.00

ASPI-2010HC-R47

0.47

M

0.049

102

4.70

4.00

3.10

2.70

ASPI-2010HC-R68

0.68

M

0.065

77

4.00

3.50

2.80

2.50

ASPI-2010HC-1R0

1.0

M

0.090

70

3.85

3.35

2.35

2.05

ASPI-2010HC-2R2

2.2

M

0.170

39

2.15

1.90

1.70

1.45

ASPI-2010HC-100

10

M

0.826

15

0.95

0.80

0.75

0.65

Test Conditions:

b. Relative Humidity: 65%±20%

c. Air Pressure: 86KPa to 106KPa

Inductance (L): WK3260B LCR meter or equivalent, 1MHz, 1V.

Direct Current Resistance (DCR): HIOKI 3540 or equivalent.

Saturation Current (Isat): WK3260B LCR meter or equivalent.

Temperature rise current (Irms): Electric Power, Electric current meter, Thermometer.

Saturation Current Max: DC current at which the inductance drops less than 30% from its value without

current.

Saturation Current Typ: DC current at which the inductance drops approximate 30% from its value

without current.

Irms: DC current that causes the temperature rise (ΔT) from 20°C ambient.

ΔT＜40°C for Irms max; ΔT is approximate 40°C for Irms typ.

ASPI-2010HC-

-

Inductance Code

Please refer to the

table above

Tolerance

M: ±20%

Packaging

T: Tape and Reel

(2kpcs / reel)
